Single-StageTWT375D-12F Air Compressor
TWT375D-12T is a single-stage compression screw air compressor with 10.6m³/min air delivery and 12bar working pressure, equipped with Cummins 112kW engine, suitable for geothermal drilling, mining and DTH hammer operations.
Product Overview
TWT375D-12F is a single-stage compression mobile screw air compressor with 375CFM/10.6m³/min air delivery and 12bar working pressure. Equipped with Cummins QSB3.9-C150-31 engine, 150HP/110kW powerful output, DNV2.7-1 certified, compact structure, stable operation, widely used in offshore oil & gas drilling, membrane nitrogen generation systems and geological exploration operations.
Mobile design, easy relocation, suitable for various drilling construction projects.
Core Advantages
Smart Control
TWT smart controller, real-time operation status monitoring, supports remote management
High Pressure & Large Delivery
12bar high pressure output, drives large diameter DTH hammers
Compact Design
Compact structure, easy relocation, suitable for frequent site changes
Cummins Engine
Cummins 112kW powerful output, low fuel consumption, high reliability
Technical Specifications
| Parameter | Specification |
|---|---|
| Air Delivery | 375 CFM / 10.6 m³/min |
| Working Pressure | 12 bar |
| Engine Brand | Cummins |
| Engine Power | 150 HP / 110 kW |
| Unit Weight | 3230 kg |
| Dimensions (L×W×H) | 2808 × 1624 × 2241 mm |
Recommended Matching Technology
| Drilling Method | Applicable Formation | Description |
|---|---|---|
| DTH Air Drilling | Hard Rock, Gravel Layer | With screw air compressor + DTH hammer |
Applications
Applicable Engineering Scenarios
Rural Water Supply Wells
High pressure large delivery design
Agricultural Irrigation Wells
Agricultural irrigation water intake, 12 bar suitable for different well diameter requirements
Hydrogeological Exploration
Hydrogeological survey and exploration, sampling and pumping test both supported
Applicable Geological Conditions
- Clay Layer
- Sand Gravel Layer
- Weathered Rock Formation
- Soft Rock Formation
